Supply voltage: 24 VDC, SELV (18 … 31.2 V); with reverse voltage protection
Operating power: 10.8 W, without USB load; 16.3 W, with USB load
Connection Data
Connection technology: communication/fieldbus: Modbus TCP/UDP: 2 x RJ-45; EtherNet/IPTM: 2 x RJ-45; CANopen: 1 x D-sub 9 plug; Modbus UDP: 2 x RJ-45; RS-232 + RS-485 serial interface: 1 x D-sub 9 socket; USB: 2 x USB 2.0 host (type A)
Connection technology: supply: 1 x included 734-103 female connector featuring three CAGE CLAMP® connections
Physical Data
Width: 420 mm / 16.535 inch
Height: 283 mm / 11.142 inch
Depth: 78 mm / 3.070 inch
Panel cutout (W x H): (406 x 268) mm
Mechanical Data
Weight: 3000.000 g
Environmental Requirements
Surrounding air temperature (operation): -20 … 55 °C (when mounted vertically; −20 … +50 °C, other mounting positions)
Surrounding air temperature (storage): -20 … 70 °C
Protection type: IP65
Note on protection type: IP65 (front side); IP20 (rear side), per EN 60529
Relative humidity (without condensation): 90 %
Mounting type: Clamping elements (included)
Fire load: 0.000 MJ
Commercial Data
Country of origin Sales Organisation Germany: DE
GTIN: 4055144002744
Customs tariff number Sales Organisation Germany: 84714100000
