Features

• The antenna is to be mounted on a plate measuring at least 9.8 x 9.8 inches (25 x 25 cm).
• The distance of interfering sources to the antenna and antenna line must be at least 11.8 inches (30 cm) and the free space between the antenna and the next wall must be at least 13.78 inches (35 cm).
• The antenna cable should, under no circumstances, be bent sharply, since irreversible damage may result to the antenna line (RG174 bend radius > 0.6 inches/15 mm).

Specifications

Technical Data

• Radio technology: Mobile communications
• Frequency band: 870 MHz … 960 MHz; 1710 MHz … 1880 MHz
• Gain: 870 MHz … 960 MHz 0 dB; 1710 MHz … 1880 MHz 0 dB
• Power (max.): 20 W
• VSWR: 870 MHz … 960 MHz < 1.5; 1710 MHz … 1880 MHz < 1.5

Mechanical Data

• Connector: SMA right angle plug + ferrite bead
• Length of connecting cable: 2.5 m

Material Data

• Fire load: 0.000 MJ
• Weight: 79.200 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: IT
• GTIN: 4044918122535
• Customs tariff number Sales Organisation Germany: 85177000000
