Specifications

Notes

• Note: The maximum range in the field decreases within buildings and varies depending on building materials and spatial geometry. Therefore, range specifications within buildings can only represent a typical value that can normally be achieved. More detailed information is available in the manual.

Technical Data

• Device specification: Master or slave
• Security encryption: 128-bit encryption
• Radio technology: Bluetooth® 2.1
• Frequency band: ISM band, 2402 … 2483 MHz
• Security authentication: Pin code or configurable access list
• Supported profiles: Serial Port Profile (SPP)
• Communication type: Peer-to-peer connection
• Coexistence: Frequency Hopping Spread Spectrum (FHSS) || Adaptive Frequency Hopping (AFH) || Adaptive transmission power with configurable upper limit || Configurable channel blacklist || Supports coexistence optimized inquiry (transmission time ≤ 0.1 s; transmission cycle ≥ 2.9 s)
• Transmission range: 20 m in open space (Class 2)
• Antenna: Integrated
• Receiver sensitivity: -82 dBm
• Configuration options: AT commands (e.g., via HyperTerminal)
• Power consumption (5 V system supply): 60 mA
• Indicators: Operating mode

Connection Data

• Contact type: 4-pole male connector
• Connection type: 4-pole male connector

Physical Data

• Width: 15 mm / 0.591 inch
• Height: 50 mm / 1.969 inch
• Depth: 19 mm / 0.748 inch

Material Data

• Color: Light gray
• Fire load: 0.000 MJ
• Weight: 16.600 g
• Conformity marking: CE

Environmental Requirements

• Surrounding air temperature (operation): -20 … 60 °C
• Protection type: IP20

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918368100
• Customs tariff number Sales Organisation Germany: 84733080000
