Features

• The antenna must be mounted on a conductive base plate measuring at least 40 x 40 cm.
• The distance of interfering sources to the antenna and antenna line must be at least 30 cm. The free space between the antenna and the next wall must be at least 35 cm.
• The antenna cable must not, under any circumstances, be bent sharply, since irreversible damage may result to the antenna line.

Specifications

Technical Data

• Radio technology: GSM || UMTS || LTE || Bluetooth® || WLAN || 5G
• Frequency band: 617 … 960 MHz; 1710 … 6000 MHz
• Gain: 617 … 960 MHz: 1dBi; 1710 … 2700 MHz: 4dBi; 3400 … 3800 MHz: 8dBi; 4900 … 6000 MHz: 9dBi

Mechanical Data

• Mounting type: Gehäuseeinbau; Klebestreifen
• Cable type: CS29
• Connector: SMA-Stecker
• Length of connecting cable: 2 m

Material Data

• Fire load: 0.000 MJ
• Weight: 185.000 g

Environmental Requirements

• Surrounding air temperature (operation): -40 … 85 °C
• Protection type: IP66

Commercial Data

• Packaging type: Bag
• Country of origin Sales Organisation Germany: CN
• GTIN: 4055144039962
• Customs tariff number Sales Organisation Germany: 85291095900
