Features

Approvals

• DEKRA Certification B.V., CCA, NTR NL-7522, EN 60947
• DEKRA Certification B.V., CCA, 2195540.01, EN 60947
• DEKRA Certification B.V., CCA, 2195540.01, IEC 60947

Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 500 V
• Rated surge voltage (III/3): 6 kV
• Rated current: 30 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Strip length: 12 … 13 mm / 0.47 … 0.51 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 8 mm / 0.315 inch
• Height: 98 mm / 3.858 inch
• Depth from upper edge of DIN-rail: 46.5 mm / 1.831 inch

Mechanical Data

• Design: Angled
• Mounting type: DIN-35 rail
• Marking level: Center/side marking

Material Data

• Color: Gray
• Flammability class per UL94: V0
• Fire load: 0.365 MJ
• Weight: 25.218 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: CN
• GTIN: 4050821227557
• Customs tariff number Sales Organisation Germany: 85369010000
