Features

Approvals

• DEKRA Certification B.V., CSA, 1565649, C22.2
• DEKRA Certification B.V., CCA, NTR NL 6828, EN 60947
• DEKRA Certification B.V., CCA, 2143311.03, EN 60947
• Underwriters Laboratories Inc., UR, E45172, UL 1059

Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 250 V
• Rated surge voltage (III/3): 4 kV
• Rated current: 18 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Note (conductor cross-section): 12 AWG: THHN, THWN
• Strip length: 6 … 7 mm / 0.24 … 0.28 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 5 mm / 0.197 inch
• Height: 68 mm / 2.677 inch
• Depth from upper edge of DIN-rail: 39 mm / 1.535 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Side marking

Material Data

• Color: Orange
• Flammability class per UL94: V0
• Fire load: 0.172 MJ
• Weight: 8.947 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: CN
• GTIN: 4050821035275
• Customs tariff number Sales Organisation Germany: 85369010000
