Note (conductor cross-section): Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
Strip length: 10 … 12 mm / 0.39 … 0.47 inch
Wiring direction: Front-entry wiring
Connection 2
Number of connection points 2: 2
Physical Data
Width: 5.2 mm / 0.205 inch
Height: 86.2 mm / 3.394 inch
Depth from upper edge of DIN-rail: 32.5 mm / 1.28 inch
Mechanical Data
Design: Horizontal type
Mounting type: DIN-35 rail
Marking level: Center/side marking
Material Data
Color: Gray
Insulation material: Polyamide (PA66)
Flammability class per UL94: V0
Fire load: 0.181 MJ
Weight: 9.293 g
Commercial Data
Packaging type: Box
Country of origin Sales Organisation Germany: CN
GTIN: 4050821145226
Customs tariff number Sales Organisation Germany: 85366990990
