Features

Approvals

• American Bureau of Shipping, ABS, 18-HG1755093-PDA
• DEKRA Certification B.V., CSA, 70048857, C22.2
• Underwriters Laboratories Inc., UR, E45172, UL 1059
• DEKRA Certification B.V., KEMA/KEUR, 71-112493, EN 60998
• DEKRA Certification B.V., CCA, NTR NL 7812, EN 60998
• Lloyds Register, LR, 04/20013 (E8), EN 60998

Specifications

Ratings Per Iec/En

• Ratings per: EN 60664
• Nominal voltage (II/2): 100 V
• Rated surge voltage (II/2): 1.5 kV
• Rated current: 6 A
• Legend (ratings): (II / 2) ≙ Overvoltage category II / Pollution degree 2

Connection 1

• Connection technology: PUSH WIRE®
• Actuation type: Push-in
• Connectable conductor materials: Copper
• Solid conductor: 22 … 20 AWG
• Conductor diameter: 0.6 … 0.8 mm / 22 … 20 AWG
• Conductor diameter (note): When using conductors of the same diameter, Ø 0.5 mm / 24 AWG or Ø 1 mm / 18 AWG are also possible.
• Strip length: 5 … 6 mm / 0.2 … 0.24 inch
• Wiring direction: Side-entry wiring

Physical Data

• Width: 10 mm / 0.394 inch
• Height: 6.8 mm / 0.268 inch
• Depth: 10 mm / 0.394 inch

Material Data

• Color: Dark gray
• Cover color: Light gray
• Fire load: 0.012 MJ
• Weight: 0.774 g

Environmental Requirements

• Surrounding air temperature (operation): 60 °C
• Continuous operating temperature: 105 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918440585
• Customs tariff number Sales Organisation Germany: 85369010000
