Features

Approvals

• DEKRA Certification B.V., CSA, 1632550, C22.2 No. 158

Specifications

Notes

• Safety information 1: Only suitable for DIN 35 x 15 rail

Ratings Per Iec/En

• Nominal voltage (III/3): 400 V
• Rated surge voltage (III/3): 6 kV
• Rated current: 125 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 6 … 35 mm² / 8 … 2 AWG
• Strip length: 23 mm / 0.91 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 16 mm / 0.63 inch
• Height: 116.5 mm / 4.587 inch
• Depth from upper edge of DIN-rail: 44.5 mm / 1.752 inch

Mechanical Data

• Design: Angled
• Mounting type: DIN-35 rail
• Marking level: Center/side marking

Material Data

• Color: Blue
• Flammability class per UL94: V0
• Fire load: 1.085 MJ
• Weight: 93.290 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454601874
• Customs tariff number Sales Organisation Germany: 85365080900
