Features

Approvals

• Bureau Veritas S.A., BV, 40179_B0, Rules for class. of Steel Ships
• CQST/CNEx, CCCEx, 2020312310000210, CNCA-C23-01
• Polski Rejestr Statków, PRS, TE/2186/880590/18
• TUEV Nord Cert GmbH, IECEx, IECEX_TUN_14.0030_X, IEC 60079-0
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAA00001D1
• TUEV Nord Cert GmbH, IECEx, TÜV_14_ATEX_112692_X, EN 60079-0
• Underwriters Laboratories Inc., UL, E175199 Vol.2 Sec.1, UL 508

Specifications

Notes

• Note: Bei den angegebenen technischen Daten handelt es sich um Maximalwerte. Diese können durch das verwendete Zubehör eingeschränkt werden.

Electrical Data

• Inputs/outputs: 8-channel analog input or output
• Operating voltage: ≤ DC 30 V
• Limiting continuous current: 1 A
• Contact resistance: ≤ 20 mΩ

Safety And Protection

• Rated voltage: 50 V
• Pollution degree: 2
• Overvoltage category: III

Connection Data

• Pole No.: 16
• Connection type (1): System
• Pole number 1: 16
• Pluggable connectors: DIN 41651 male connector
• Connection type 2: Field
• Pole number 2: 16
• Design 2: Plug for jumper slot
• Performance level: 3

Mechanical Data

• Mounting type: Pluggable module

Material Data

• Fire load: 0.571 MJ
• Weight: 41.400 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 70 °C
• Surrounding air temperature (storage): -40 … 85 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Operating altitude (max.): 2000 m

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454995164
• Customs tariff number Sales Organisation Germany: 85369010000
