Features

Approvals

• UL International Netherlands B.V., UL, E175199 Sec.4, UL 508
• TUEV Nord Cert GmbH, IECEx, IECEX_TUN_14.0030_X, IEC 60079-0
• Polski Rejestr Statków, PRS, TE/2186/880590/18
• CQST/CNEx, CCCEx, 2020312310000210, CNCA-C23-01
• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAA00001D1
• Brjansker Zertifizierungsstelle, EAC, EAC RU C-DE.AM02.B.00144/19, TP TC 012/2011
• Underwriters Laboratories Inc., UL, E198726, ANSI/ISA 12.12.01
• TUEV Nord Cert GmbH, IECEx, TÜV_14_ATEX_112692_X, EN 60079-0

Specifications

Operating Data

• Operating voltage: ≤ AC/DC 33 V
• Continuous current (max.): 8 A
• Contact resistance: ≤ 10 mΩ

Safety And Protection

• Protection type: IP20

Connection Data

• Connection technology: Push-in CAGE CLAMP®
• Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Fine-stranded conductor: 0.34 … 2.5 mm² / 22 … 14 AWG
• Strip length: 9 … 10 mm / 0.35 … 0.39 inch

Physical Data

• Width: 6 mm / 0.236 inch
• Height: 94 mm / 3.701 inch
• Depth from upper edge of DIN-rail: 97.8 mm / 3.85 inch

Mechanical Data

• Mounting type: DIN-35 rail

Material Data

• Fire load: 0.000 MJ
• Weight: 28.800 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 70 °C
• Surrounding air temperature (storage): -40 … 85 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Operating altitude (max.): 2000 m

Standards And Specifications

• Conformity marking: CE

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821088189
• Customs tariff number Sales Organisation Germany: 85437090300
