WAGO 788-185

788-185 WAGO 788-185

WAGO 788-185
Part # 788-185
Manufacturer WAGO
GTIN 4050821868095
Condition New
Price: $ 999.99

Please Contact Us for Stock Availability

Qty
Order by 3PM MST (subject to stock availability) same day shipping available!
**DISCONTINUED-PLEASE CALL #949-645-9900 FOR ASSISTANCE**RELAY 24VDC 2U RP
Got questions? Send us a message or call us at 1-800-335-5111 for additional assistance.
Pluggable miniature switching relays DC 24 V 25 mm high

Specifications

Control Circuit

  • Nominal input voltage UN: DC 24 V

Load Circuit

  • Number of changeover/switchover contacts: 2
  • Contact material (relay): AgCdO
  • Limiting continuous current: 8 A
  • Switching voltage (max.): AC 250 V
  • Switching power (resistive) (max.): AC 2000 VA
  • Pull-in time (typ.): 9 ms
  • Drop-out time (typ.): 3 ms

Safety And Protection

  • Dielectric strength, control/load circuit (AC, 1 min): 5 kVrms
  • Dielectric strength, open contact (AC, 1 min): 1 kVrms
  • Dielectric strength, load/load circuit (AC, 1 min): 2.5 kVrms

Physical Data

  • Width: 12.7 mm / 0.5 inch
  • Height from the surface: 25.5 mm / 1.004 inch
  • Depth: 29 mm / 1.142 inch

Mechanical Data

  • Mounting type: Pluggable module

Material Data

  • Fire load: 0.263 MJ
  • Weight: 17.000 g

Environmental Requirements

  • Surrounding air temperature (operation at UN): -40 … 85 °C
  • Surrounding air temperature (storage): -40 … 85 °C

Standards And Specifications

  • Standards/Specifications: EN 61810-1

Commercial Data

  • Packaging type: Box
  • Country of origin Sales Organisation Germany: CZ
  • GTIN: 4050821868095
  • Customs tariff number Sales Organisation Germany: 85364900990
: *
: *
: *
