Specifications

Control Circuit

• Nominal input voltage UN: DC 12 V

Load Circuit

• Number of changeover/switchover contacts: 2
• Contact material (relay): AgCdO
• Limiting continuous current: 8 A
• Switching voltage (max.): AC 250 V
• Switching power (resistive) (max.): AC 2000 VA
• Pull-in time (typ.): 9 ms
• Drop-out time (typ.): 3 ms

Safety And Protection

• Dielectric strength, control/load circuit (AC, 1 min): 5 kVrms
• Dielectric strength, open contact (AC, 1 min): 1 kVrms
• Dielectric strength, load/load circuit (AC, 1 min): 2.5 kVrms

Physical Data

• Width: 12.7 mm / 0.5 inch
• Height from the surface: 25.5 mm / 1.004 inch
• Depth: 29 mm / 1.142 inch

Mechanical Data

• Mounting type: Pluggable module

Material Data

• Fire load: 0.000 MJ
• Weight: 18.000 g

Environmental Requirements

• Surrounding air temperature (operation at UN): -40 … 85 °C
• Surrounding air temperature (storage): -40 … 85 °C

Standards And Specifications

• Standards/Specifications: EN 61810-1

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: CZ
• GTIN: 4050821867951
• Customs tariff number Sales Organisation Germany: 85364900990
