WAGO 289-722

289-722 WAGO 289-722

WAGO 289-722
Part # 289-722
Manufacturer WAGO
GTIN 4045454424589
Condition New
Price: $ 93.93

Please Contact Us for Stock Availability

Qty
Order by 3PM MST (subject to stock availability) same day shipping available!
INTERFACE MOD MINI D-SUB HDR 25POLES
Got questions? Send us a message or call us at 1-800-335-5111 for additional assistance.
Interface module with sub miniature d-male connector 25 pole

Specifications

Notes

  • Note: One solder terminal per pole is available for testing and patching (except for shield contact).

Electrical Data

  • Operating voltage: ≤ AC/DC 125 V
  • Nominal current: 2 A
  • Contact resistance (max.): 30 mΩ
  • Specialty functions: With solder pin || With shield connection

Safety And Protection

  • Rated voltage: 50 V
  • Rated surge voltage: 0.8 kV
  • Pollution degree: 2
  • Protection type: IP00*
  • Note on protection type: Notice! Live parts can be easily touched! Protection against direct contact must be provided by the equipment manufacturer, e.g., using a WAGO 709 Series Cover (see “Accessories”) or a similar cover. The installation guidelines must be observed for each individual application.

Connection Data

  • Pole No.: 25
  • Connection type (1): System
  • Pluggable connectors: D-sub male connector
  • For mating connector: With solder contact
  • Mating direction: Vertical
  • Connection type 2: Field
  • Pole number 2: 26
  • Design 2: PCB terminal blocks (double-deck)
  • Connection technology 2: CAGE CLAMP®
  • WAGO Connector 2: WAGO 736 Series
  • Solid conductor 2: 0.08 … 2.5 mm² / 28 … 12 AWG
  • Fine-stranded conductor 2: 0.08 … 2.5 mm² / 28 … 12 AWG
  • Strip length 2: 5 … 6 mm / 0.2 … 0.24 inch
  • Note (conductor cross-section): 12 AWG: THHN, THWN
  • Performance level: 2 / 200 mating cycles
  • Strain relief: UNC 4-40 stud bolt

Physical Data

  • Width: 69 mm / 2.717 inch
  • Height: 85 mm / 3.346 inch
  • Depth from upper edge of DIN-rail: 48 mm / 1.89 inch

Mechanical Data

  • Mounting type: DIN-35 rail
  • Housing design: Mounting carrier

Material Data

  • Contact material (connector): Au over Ni
  • Fire load: 0.927 MJ
  • Weight: 96.870 g

Environmental Requirements

  • Surrounding air temperature (operation): -20 … 50 °C
  • Surrounding air temperature (storage): -40 … 70 °C
  • Relative humidity: ≤ 85% (non-condensing)

Commercial Data

  • Packaging type: Box
  • Country of origin Sales Organisation Germany: DE
  • GTIN: 4045454424589
  • Customs tariff number Sales Organisation Germany: 85366990990
: *
: *
: *
