Specifications

Electrical Data

• Nominal current: 1.5 A
• Insulation resistance: ≥ 500 MΩ
• Specialty functions: With shield connection

Safety And Protection

• Dielectric strength, contact/contact (AC, 1 min): 1 kVrms

Connection Data

• Pole No.: 8
• Connection type (1): System
• Pluggable connectors: RJ-45 (shielded)
• Connection type 2: System
• Pole number 2: 5
• Design 2: PCB terminal blocks
• Connection technology 2: CAGE CLAMP®
• WAGO Connector 2: WAGO 739 Series
• Solid conductor 2: 0.08 … 1.5 mm² / 28 … 14 AWG
• Fine-stranded conductor 2: 0.08 … 1.5 mm² / 28 … 14 AWG
• Strip length 2: 5 … 6 mm / 0.2 … 0.24 inch
• Mating cycles: 500
• Transmission length (max.): 100 m
• Connection cable: Cat. 5 (min.)

Physical Data

• Width: 24 mm / 0.945 inch
• Height: 85 mm / 3.346 inch
• Depth from upper edge of DIN-rail: 40 mm / 1.575 inch

Mechanical Data

• Mounting type: DIN-35 rail
• Housing design: Mounting carrier

Material Data

• Fire load: 0.519 MJ
• Weight: 32.600 g

Environmental Requirements

• Surrounding air temperature (operation): -40 … 85 °C (Actuation: −35 … +85 °C)
• Surrounding air temperature (storage): -40 … 85 °C
• Relative humidity: ≤ 85% (non-condensing)

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454317492
• Customs tariff number Sales Organisation Germany: 85366990990
