Specifications

Electrical Data

• Operating voltage: ≤ AC/DC 250 V
• Current per connection (max.): 12 A
• Total current per potential (max.): 32 A

Safety And Protection

• Rated voltage: 250 V
• Rated surge voltage: 4 kV
• Pollution degree: 2

Connection Data

• Total number of potentials: 4
• Connection type (1): Power supply
• Mating direction: 45°
• Connection technology: CAGE CLAMP®
• WAGO Connector: WAGO 745 Series
• Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
• Strip length: 11 … 12 mm / 0.43 … 0.47 inch
• Connection type 2: Connection points
• Mating direction (2): 45°
• Connection technology 2: CAGE CLAMP®
• WAGO Connector 2: WAGO 739 Series
• Solid conductor 2: 0.08 … 2.5 mm² / 28 … 12 AWG
• Fine-stranded conductor 2: 0.08 … 2.5 mm² / 28 … 12 AWG
• Strip length 2: 8 … 9 mm / 0.31 … 0.35 inch
• Note (conductor cross-section): 12 AWG: THHN, THWN

Physical Data

• Width: 115 mm / 4.528 inch
• Height: 85 mm / 3.346 inch
• Depth from upper edge of DIN-rail: 45 mm / 1.772 inch

Mechanical Data

• Mounting type: DIN-35 rail
• Housing design: Mounting carrier

Material Data

• Fire load: 1.439 MJ
• Weight: 178.200 g

Environmental Requirements

• Surrounding air temperature (operation): -20 … 50 °C
• Surrounding air temperature (storage): -40 … 80 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454287092
• Customs tariff number Sales Organisation Germany: 85369010000
