Specifications

Input

• Phases: 1
• Nominal input voltage Ui nom: 1 x AC 230 V
• Input voltage range: ±10 %
• Nominal mains frequency range: 50 … 60 Hz

Output

• Nominal output voltage Uo nom: DC 15 / -15 V
• Output voltage range: ±4 %
• Nominal output current Io nom: 2 x 0.5 A
• Residual ripple: ≤ 10 mV (Peak-to-peak)

Efficiency/Power Losses

• Power loss (max.) Pl (max.): 27 W

Circuit Protection

• Internal fuse: 2 x T 0.8 A

Safety And Protection

• Protection class: III
• Protection type: IP00 (per EN 60529)
• Pollution degree: 2
• Series operation: No

Connection Data

• Connection technology: CAGE CLAMP®
• WAGO Connector: WAGO 236 Series
• Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Strip length: 5 … 6 mm / 0.2 … 0.24 inch
• Note (conductor cross-section): 12 AWG: THHN, THWN

Physical Data

• Width: 94 mm / 3.701 inch
• Height: 106 mm / 4.173 inch
• Depth from upper edge of DIN-rail: 57 mm / 2.244 inch

Mechanical Data

• Mounting type: DIN-35 rail

Material Data

• Fire load: 1.271 MJ
• Weight: 681.779 g

Environmental Requirements

• Surrounding air temperature (operation): 0 … 40 °C

Standards And Specifications

• Conformity marking: CE

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821155515
• Customs tariff number Sales Organisation Germany: 85044082900
