Specifications

Input

• Nominal input voltage Ui nom: AC 24 V
• Input voltage range: ±10 %

Output

• Nominal output voltage Uo nom: DC 24 V
• Output voltage range: ±10 %
• Nominal output current Io nom: 5 A

Safety And Protection

• Protection class: III
• Protection type: IP00 (per EN 60529)
• Pollution degree: 2
• Series operation: No

Connection Data

• Connection technology: CAGE CLAMP®
• WAGO Connector: WAGO 236 Series
• Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Strip length: 5 … 6 mm / 0.2 … 0.24 inch
• Note (conductor cross-section): 12 AWG: THHN, THWN

Physical Data

• Width: 170 mm / 6.693 inch
• Height: 108 mm / 4.252 inch
• Depth from upper edge of DIN-rail: 85 mm / 3.346 inch

Mechanical Data

• Mounting type: DIN-35 rail

Material Data

• Fire load: 4.422 MJ
• Weight: 634.000 g

Environmental Requirements

• Surrounding air temperature (operation): 0 … 30 °C

Standards And Specifications

• Conformity marking: CE

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4017332160445
• Customs tariff number Sales Organisation Germany: 85044082900
