Specifications

Electrical Data

• Nominal operating voltage: DC 24 V
• Power consumption at nominal supply voltage: ≤ 28 mA
• Voltage drop at input: 23 … 850 mV
• Measurement span (max.): 1 … 10 AAC
• Switching threshold (adjustable) (min.): 1 A
• Response time: 200 ms
• Number of changeover/switchover contacts: 1
• Number of break/switch-off contacts: 1
• Limiting continuous current: 5 A
• Switching voltage (max.): AC 250 V
• Switching power (resistive) (max.): AC 1250 VA
• Status indicator: Red LED; Energized relay (current < switching threshold)

Safety And Protection

• Rated voltage: 250 V
• Rated surge voltage: 4 kV
• Pollution degree: 2
• Dielectric strength, input/output (AC, 1 min): 1.5 kVrms

Physical Data

• Height from upper-edge of DIN-rail: 82.5 mm / 3.25 inch
• Depth: 52 mm / 2.047 inch

Mechanical Data

• Mounting type: Pluggable module for receptacle terminal blocks
• Housing design: Plug for carrier terminal blocks

Material Data

• Color: Light gray
• Fire load: 9.483 MJ
• Weight: 58.000 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 40 °C
• Surrounding air temperature (storage): -40 … 70 °C
• Relative humidity: 5 … 85 % (no condensation permissible)
• Operating altitude (max.): 2000 m

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4050821254850
• Customs tariff number Sales Organisation Germany: 85364900990
