Specifications

Electrical Data

• Operating voltage: DC 12 … 28 V
• Voltage drop at input: 24 … 210 mV
• Measurement span (max.): 0.4 … 3.5 ADC (−20 … +40 °C); 0.4 … 3 ADC (−20 … +60 °C); 0.4 … 2 ADC (−20 … +70 °C)
• Turn on/off point: 0.35 A / 0.07 A
• Response time: 0.5 ms
• Number of make/switch-on contacts: 1
• Limiting continuous current: 0.5 A
• Switching voltage (max.): DC 200 V
• Switching power (resistive) (max.): DC 10 W

Safety And Protection

• Dielectric strength, input/output (AC, 1 min): 1.5 kVrms

Physical Data

• Height from upper-edge of DIN-rail: 82.5 mm / 3.25 inch
• Depth: 52 mm / 2.047 inch

Mechanical Data

• Mounting type: Pluggable module for receptacle terminal blocks
• Housing design: Plug for carrier terminal blocks

Material Data

• Color: Light gray
• Fire load: 0.324 MJ
• Weight: 22.700 g

Environmental Requirements

• Surrounding air temperature (operation): -25 … 40 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Operating altitude (max.): 2000 m

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454415730
• Customs tariff number Sales Organisation Germany: 85364900990
