WAGO 857-181

857-181 WAGO 857-181

WAGO 857-181
Part # 857-181
Manufacturer Wago
GTIN 4055143724319
Condition New
Price: $ 40.98

Please Contact Us for Stock Availability

Qty
Order by 3PM MST (subject to stock availability) same day shipping available!
Basic solid-state relay; Nominal input voltage: 24 VDC; Output voltage range: 0 … 24 VDC
Got questions? Send us a message or call us at 1-800-335-5111 for additional assistance.
Basic solid-state relay; Nominal input voltage: 24 VDC; Output voltage range: 0 … 24 VDC

Features

Approvals

  • Underwriters Laboratories Inc., UL, E340707, UL 508

Specifications

Notes

  • Note: Optocouplers and solid state relays are designed for use in signal processing networks, which are not supplied by the low-voltage power supply networks.

Control Circuit

  • Nominal input voltage UN: DC 24 V (SELV)
  • Input voltage range (low level): DC 0 … 4 V
  • Input voltage range (high level): DC 16.8 … 30 V
  • Nominal input current at UN: 7 mA

Load Circuit

  • Circuit type: 2-wire connection
  • Limiting continuous current: 8 A
  • Nominal output voltage: DC 24 V (SELV)
  • Output voltage range: DC 1 … 30 V
  • Voltage drop at output (max.): ≤ DC 0.8 V
  • Leakage current at rated voltage: ≤ 1 µA
  • Switching current (min.): 10 mA
  • Turn-on time: ≤ 60 µs
  • Turn-off time: ≤ 250 µs
  • Switching frequency: ≤ 500 Hz

Safety And Protection

  • Dielectric strength, control/load circuit (AC, 1 min): 3.51 kVrms

Physical Data

  • Width: 5 mm / 0.197 inch
  • Height from the surface: 15 mm / 0.591 inch
  • Depth: 28 mm / 1.102 inch

Mechanical Data

  • Mounting type: Pluggable module

Material Data

  • Fire load: 0.000 MJ
  • Weight: 3.600 g

Environmental Requirements

  • Surrounding air temperature (operation at UN): -30 … 80 °C
  • Surrounding air temperature (storage): -40 … 100 °C
  • Relative humidity: 5 … 95 % (no condensation permissible)
  • Operating altitude (max.): 2000 m

Commercial Data

  • Packaging type: Box
  • Country of origin Sales Organisation Germany: DE
  • GTIN: 4055143724319
  • Customs tariff number Sales Organisation Germany: 85365005000
: *
: *
: *
