Specifications

Notes

• Note: When using more than 10 wires, the maximum current per wire must be reduced to 0.7 A.

Electrical Data

• Inputs/outputs: 16 digital outputs
• Operating voltage: ≤ AC/DC 35 V
• Current per wire (max.): 1 A

Connection Data

• Compatible PLC Modules: Rockwell Compact Logix
• Compatible PLC I/O Card Types: 1769 - OB16 || 1769 - OB16P
• Connection type (1): System
• Pole number 1: 20
• Pluggable connectors: Pluggable connector per DIN 41651; Female connector
• Connection type 2: System
• Pole number 2: 18
• Connector 2: Rockwell-RTBN18
• Cable type: LiYY
• Wire cross-section: 0.14 mm²
• Color code: Per DIN VDE 47100

Physical Data

• Cable length: 2 m

Material Data

• Fire load: 0.000 MJ
• Weight: 239.000 g

Environmental Requirements

• Surrounding air temperature (operation): -20 … 50 °C

Commercial Data

• Country of origin Sales Organisation Germany: FR
• GTIN: 4045454883195
• Customs tariff number Sales Organisation Germany: 85444290900
