Features

Approvals

• Physikalisch Technische Bundesanstalt, IECEx, IECEx PTB 13.0004U Ex ec IIC Gc, IEC 60079-0
• Physikalisch Technische Bundesanstalt, ATEX, PTB 13 ATEX 1004 UII3 G Ex ec II C Gc, EN IEC 60079-0
• Underwriters Laboratories Inc., UL, E45172, UL 1059
• CQST/CNEx, CCCEx, 2020312313000255, CNCA-C23-01
• DEKRA Certification B.V., CCA, 2437422, C22.2 No. 158

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-1
• Rated current: 20 A

Ratings Per Ul

• Approvals per: UL 1059
• Rated voltage UL (Use Group B): 600 V
• Rated current UL (Use Group B): 20 A
• Rated voltage UL (Use Group C): 600 V
• Rated current UL (Use Group C): 20 A

Ratings Per Csa

• Approvals per: C22.2 No 158
• Rated voltage CSA (Use Group C): 600 V
• Rated current CSA (Use Group C): 20 A

Ex Information

• Rated voltage EN (Ex e II): 630 V

Connection Data

• Total number of potentials: 1
• Number of levels: 1

Physical Data

• Width: 5.2 mm / 0.205 inch
• Height: 52 mm / 2.047 inch
• Depth from upper edge of DIN-rail: 32.5 mm / 1.28 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Center/side marking

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.125 MJ
• Weight: 5.490 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: CN
• GTIN: 4055143828833
• Customs tariff number Sales Organisation Germany: 85366990990
