Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-2

Ratings Per Ul

• Approvals per: UL 1059

Ratings Per Csa

• Approvals per: C22.2 No 158

Connection 1

• Connection technology: Screw-type connection
• Actuation type: T-wrench; 4 mm
• Connectable conductor materials: Copper
• Nominal cross-section: 70 mm²
• Solid conductor: 10 … 95 mm² / 8 … 3/0 AWG
• Stranded conductor: 10 … 95 mm² / 8 … 3/0 AWG
• Fine-stranded conductor: 10 … 70 mm² / 8 … 2/0 AWG
• Fine-stranded conductor; with insulated ferrule: 10 … 70 mm² / 8 … 2/0 AWG
• Strip length: 22 mm / 0.87 inch
• Wiring direction: Side-entry wiring
• Screw thread: M5

Physical Data

• Width: 20.5 mm / 0.807 inch
• Height: 76.5 mm / 3.012 inch
• Depth from upper edge of DIN-rail: 84 mm / 3.307 inch

Mechanical Data

• Tightening torque: 2.5 … 4 Nm
• Design: Horizontal type
• Mounting type: DIN-rail 35 x 15; 2.3 mm thick; copper
• Marking level: Side marking

Material Data

• Color: Green-yellow
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.000 MJ
• Weight: 192.000 g

Environmental Requirements

• Continuous operating temperature: -35 … +105 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143940825
• Customs tariff number Sales Organisation Germany: 85369010000
