Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-1
• Nominal voltage (III/3): 1000 V
• Rated surge voltage (III/3): 8 kV
• Rated current: 380 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Ratings Per Ul

• Approvals per: UL 1059
• Rated voltage UL (Use Group B): 600 V
• Rated current UL (Use Group B): 370 A
• Rated voltage UL (Use Group C): 600 V
• Rated current UL (Use Group C): 370 A

Ratings Per Csa

• Approvals per: C22.2 No 158
• Rated voltage CSA (Use Group C): 600 V
• Rated current CSA (Use Group C): 370 A

Connection 1

• Connection technology: Screw-type connection
• Actuation type: T-wrench; 8 mm
• Connectable conductor materials: Copper
• Nominal cross-section: 240 mm²
• Solid conductor: 70 … 240 mm² / 2/0 AWG … 500 kcmil
• Stranded conductor: 70 … 240 mm² / 2/0 AWG … 500 kcmil
• Fine-stranded conductor: 70 … 240 mm² / 2/0 AWG … 500 kcmil
• Fine-stranded conductor; with insulated ferrule: 70 … 185 mm² / 2/0 AWG … 350 kcmil
• Strip length: 38 mm / 1.5 inch
• Wiring direction: Side-entry wiring
• Screw thread: M10

Physical Data

• Width: 36 mm / 1.417 inch
• Height: 93 mm / 3.661 inch
• Depth from upper edge of DIN-rail: 126.3 mm / 4.972 inch

Mechanical Data

• Tightening torque: 10 … 20 Nm
• Design: Horizontal type
• Mounting type: DIN-35/32 rail
• Marking level: Side marking

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V2
• Fire load: 0.000 MJ
• Weight: 352.400 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143940641
• Customs tariff number Sales Organisation Germany: 85369010000
