Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 1000 V
• Rated surge voltage (III/3): 6 kV
• Rated current: 57 A

Connection 1

• Connection technology: Screw-type connection
• Actuation type: Slot screwdriver; (4 x 0.8) mm blade
• Nominal cross-section: 10 mm²
• Solid conductor: 0.2 … 10 mm² / 22 … 8 AWG
• Stranded conductor: 0.2 … 10 mm² / 24 … 8 AWG
• Fine-stranded conductor: 0.2 … 10 mm² / 22 … 8 AWG
• Fine-stranded conductor; with insulated ferrule: 0.2 … 10 mm² / 22 … 8 AWG
• Strip length: 12 mm / 0.47 inch

Mechanical Data

• Tightening torque: 1.2 … 2 Nm

Material Data

• Color: Beige
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V2
• Fire load: 0.000 MJ
• Weight: 12.610 g

Environmental Requirements

• Continuous operating temperature: -35 … +105 °C

Commercial Data

• Packaging type: Bag
• Country of origin Sales Organisation Germany: DE
• GTIN: 4055143940283
• Customs tariff number Sales Organisation Germany: 85366990990
