Features

Approvals

• Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE00001V2
• DEKRA Certification B.V., CCA, NTR NL-7078, EN 60947
• Underwriters Laboratories Inc., UL, E45172, UL 1059
• Bureau Veritas S.A., BV, 07436/F0 BV, EN 60947
• DEKRA Certification B.V., CSA, 1536073, C22.2 No. 158
• DEKRA Certification B.V., CCA, 2160584.03, EN 60947

Specifications

Ratings Per Iec/En

• Nominal voltage (III/3): 800 V
• Rated surge voltage (III/3): 8 kV
• Rated current: 125 A
• Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

• Connection technology: CAGE CLAMP®
• Number of connection points: 3
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 0.2 … 10 mm² / 24 … 8 AWG
• Fine-stranded conductor: 0.2 … 10 mm² / 24 … 8 AWG
• Strip length: 12 … 14 mm / 0.47 … 0.55 inch
• Wiring direction: Front-/side-entry wiring

Connection 2

• Connection technology 2: Screw-type connection
• Number of connection points 2: 1
• Solid conductor 2: 0.5 … 35 mm² / 10 … 2 AWG
• Fine-stranded conductor 2: 6 … 35 mm² / 10 … 2 AWG

Physical Data

• Width: 17.5 mm / 0.689 inch
• Height: 89 mm / 3.504 inch
• Depth from upper edge of DIN-rail: 39.5 mm / 1.555 inch

Mechanical Data

• Design: Horizontal type
• Mounting type: DIN-35 rail
• Marking level: Side marking
• Torque: 3.5 Nm

Material Data

• Color: Gray
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 0.000 MJ
• Weight: 55.500 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: IN
• GTIN: 4045454282561
• Customs tariff number Sales Organisation Germany: 85369010000
