Features

• 2 ETHERNET interfaces for connecting to field devices and IT networks
• 4 USB ports for the optional connection of a USB stick, mouse or keyboard
• HDMI and display port interfaces for connecting a display

Approvals

• Underwriters Laboratories Inc., UL, E482462, UL 62368-1

Specifications

Technical Data

• ETHERNET protocols: DHCP || DNS || HTTP || HTTPS || SSH || SCP || SFTP
• Visualization: Webserver
• Operating system: Debian Linux 10.5
• Processor: Intel® Atom Quad Core E3845 1.91 GHz
• Main memory (RAM): 8 GB; DDR3L 1333 MHz
• Internal memory (flash): 64 GB; mSATA SSD
• Indicators: 3 LEDs
• Supply voltage: 24 VDC (10 … 36 V)
• Input current (typ.) at nominal load (24 V): 1250 mA
• Max. input current (24 V): 1750 mA
• Operating power: 30 W typ.; 42 W max.

Connection Data

• Connection technology: communication/fieldbus: 2 x RJ-45 1000BASE-T; 3 x USB 2.0 (Type A); 1 x USB 3.0 (Type A)

Physical Data

• Width: 40 mm / 1.575 inch
• Height: 150 mm / 5.906 inch
• Depth: 105 mm / 4.134 inch

Mechanical Data

• Weight: 1309.000 g
• Housing material: Aluminum, powder-coated

Environmental Requirements

• Surrounding air temperature (operation): -20 … 60 °C
• Surrounding air temperature (storage): -40 … 85 °C
• Protection type: IP40
• Relative humidity (without condensation): 95 %
• Mounting type: DIN-35 rail
• Fire load: 0.000 MJ

Commercial Data

• Country of origin Sales Organisation Germany: TW
• GTIN: 4055144055108
• Customs tariff number Sales Organisation Germany: 84715000000
